Board-in Connector

(Total 13 Products)

  • 3.96mm Board To Board Connectors

    Get Latest Price

    Min. Order:1

    Model No:B3951Series

    The JSW B3951H-NP is a 3.96mm pitch connector designed for stable power and signal transfer in medium-to-high-current electronic assemblies. Offered in 2 to 15 positions, it supports 7A and 250V AC/DC, making it suitable for compact devices that...

  • 2.5mm Board To Board Connectors

    Get Latest Price

    Min. Order:1

    Model No:B2513Series

    The JSW B2513H-NP is a 2.5mm pitch connector designed for board-level signal transmission in compact electronic systems. Available in 2 to 16 positions, it delivers stable performance at 250V AC/DC and 2.5A, supported by PA66 UL94V-0 housing for...

  • 1.8mm Board To Board Connectors

    Get Latest Price

    Min. Order:1

    Model No:B1811TSeries

    The JSW 1.8mm board-to-board connector is engineered for compact electronic assemblies where stable signal transmission and tight spacing are essential. Built with high-conductivity phosphor bronze, it supports AWG18–22 wires and ensures reliable...

  • 2.5mm SMT Pin Header Connector Electronic Modules

    Get Latest Price

    Min. Order:1

    Model No:B2512Series

    The B2512HR-NP 2.5mm SMT Pin Header Connector is designed for precise and efficient electrical connections in modern electronic modules and industrial control systems. Featuring 2–16 poles with a compact 2.5mm pitch, it supports up to 2.5A current...

  • 2.5mm surface mount pin header

    Get Latest Price

    Min. Order:1

    Model No:B2512Series

    The B2512HV-NP 2.5mm Surface Mount Pin Header is engineered for precise, high-reliability PCB connections in both industrial and consumer electronic systems. Supporting 2–16 poles with a 2.5mm pitch, this connector handles 250V AC/DC and up to 2.5A...

  • 2.0mm DIP Pin Header Connector PCB Mounting

    Get Latest Price

    Min. Order:1

    Model No:B2011Series

    The B2011HV-NP 2.0mm DIP Pin Header Connector is designed for precise through-hole PCB mounting, delivering reliable electrical performance for compact electronic systems and industrial automation. Featuring 2–16 poles with a 2.0mm pitch, this...

  • 2.0mm surface mount pin header

    Get Latest Price

    Min. Order:1

    Model No:B2011Series

    The B2011HR-NP 2.0mm surface mount pin header is designed to deliver reliable electrical connectivity in compact PCB assemblies and high-density electronic layouts. Supporting 2–16 poles with a precise 2.0mm pitch, it is rated for 250V AC/DC and 1A...

  • 3.96mm pitch standard pin header connector

    Get Latest Price

    Min. Order:1

    Model No:B3964Series

    The B3964V-NP 3.96mm pitch standard Pin Header Connector is designed for reliable performance in industrial, power control, and electronic system applications. With 2–12 poles and a 3.96mm pitch, it supports a rated current of 7A and voltage of 250V...

  • 2.00mm pin header connector suitable for industrial

    Get Latest Price

    Min. Order:1

    Model No:B2011Series

    The B2011HV-NP 2.00mm Pin Header Connector is designed for industrial electronics requiring precise and reliable connections. With 2–16 poles and a 2.0mm pitch, this B2011HV-NP 2.00mm Header supports 250V AC/DC at 1A, providing excellent insulation...

  • 2.00mm pitch standard pin header connector

    Get Latest Price

    Min. Order:1

    Model No:B2011Series

    The B2011HR-NP 2.00mm pitch standard Pin Header Connector is designed for reliable electronic connections, accommodating 2–16 poles with a rated voltage of 250V AC/DC and a current rating of 1A. Constructed from durable PA66 UL94V-0 material, this...

  • 3.96mm Pitch Pin Header Connector

    Get Latest Price

    Min. Order:1

    Model No:B3964Series

    The 3.96mm Pitch Pin Header Connector (B3964V-NP) is a robust pin header connector designed for high-current Connector applications. With 2–12 poles and a 3.96mm pitch, it delivers up to 7A current at 250V AC/DC, making it ideal for power...

  • Industrial grade 2.50mm pin header connector

    Get Latest Price

    Min. Order:1

    Model No:B2512Series

    The B2512HR-NP industrial 2.50mm Pin Header Connector is designed for precision and reliability in electronic assemblies and industrial equipment. With 2–16 poles and a 2.50mm pitch, this durable B2512HR-NP Header supports 250V AC/DC and 2.5A...

  • 2.50mm pin header connector suitable for machines

    Get Latest Price

    Min. Order:1

    Model No:B2512Series

    The B2512HV-NP 2.50mm Pin Header Connector is designed for industrial and electronics applications requiring reliable and precise connectivity. Its Connectors design ensures secure connections in machine and automation systems, while also being...

Board-in Connector
The Board-in Connector is a compact type of electronic connector designed to be directly soldered onto a PCB, achieving electrical connection by inserting wire ends into the board. This series is known for its stability, heat resistance, and vibration durability, making it widely used in computer motherboards, communication equipment, automotive electronics, LED lighting, and industrial control systems. With its compact design and efficient assembly structure, it supports high-density wiring and reliable performance in limited spaces.

Product Features

Application Scenarios
  • Computers & Motherboards
    Applied in CPU modules, memory slots, and USB circuits for low-loss high-speed data transfer.
  • IoT and Smart Devices
    Ideal for IoT terminals, smart locks, and wearable technology.
  • Medical Equipment
    Used in diagnostic and monitoring systems requiring precision low-noise connectivity.
  • Home Appliance Control Units
    Used in appliance control boards like air conditioners and washing machines.
Product Concept
Please listen to us
At JSWGD, our product philosophy is “Precision Connection, Stable Transmission.” The Board-in connector series is developed to deliver both high reliability and efficient assembly through precise structural design and eco-friendly materials. Driven by customer needs, we provide flexible customization to ensure every connection point contributes to overall system stability.
Original concept
FAQ
How does a Board-in connector differ from a wire-to-board type?
The Board-in type allows wires to be directly inserted into the PCB, reducing assembly parts and space requirements.
Can it be used in automatic soldering processes?
Yes, it is compatible with SMT and wave soldering processes thanks to its heat-resistant materials.
Is it resistant to vibration and temperature changes?
Yes, it passes automotive-grade vibration and thermal cycle tests.
How is contact retention ensured?
A spring-supported terminal design ensures consistent contact pressure.
